P2T-12G18G-45-R-SFF-10W Switch

Available from Planar Monolithics Industries, Inc.

PMI Model No. P2T-12G18G-45-R-SFF-10W is an independently controlled, high power, reflective single pole two throw switch designed to operate between 12.0 to 18.0GHz and handle input power levels up to 10 Watts CW and 30 Watts Peak with a maximum pulse width of 1usec and maximum PRF of 2MHz. This switch offers low loss of 1.5dB maximum and provides port to port isolation of 45dB minimum. The Rise/Fall times are less than 20nsec with Delay On/Off times of less than 50nsec. The switch is controlled by two independent TTL control lines and operates at +15V, 75mA and -15V, 5mA typically. This model is supplied in a small package measuring 1.2” x 1.0” x 0.5”.
