Impedance Matching Pads

Available from Broadwave Technologies Inc.
Product Menu
View Company Profile View all Products

Product Details

BroadWave Technologies has a complete line of impedance matching pads for Satellite Communications applications. Impedance matching pads from BroadWave eliminate impedance discontinuity (mismatches) without introducing reflection to the circuit. Model 851-879-FM2 is a 50 to 75 Ohm impedance matching pad operating from DC to 2 GHz. This 1 Watt unit offers nominal insertion loss of 5.7 dB and VSWR of 1.40:1 with SMA female / F male connectors. Custom units are available in a variety of impedance and connector types from DC to 4 GHz. BroadWave Technologies impedance matching pads preserve signal integrity by matching virtually any transmission line.
