Programmable Attenuator

Programmable Attenuator

Model 651-025-127 is a 50 Ohm programmable attenuator with SMA female connectors (other impedance values and connector types are available).These solid-state units are TTL controlled via a 10-pin latch connector. BroadWave programmable attenuators are ideal for automated testing, research and development as well as programmable matrix assemblies. These devices operate 500-2500 MHz and have a 0-127 dB dynamic range with 1 dB binary steps. Attenuation accuracy is +/-0.5 dB and typical switching speed is 2 microseconds.
