High Frequency, High Current Spring Probe Catalog

Available from Signal Integrity, Inc.

The choice of spring probe will determine the maximum frequency that a socket can operate. This is usually marked as the pin bandwidth where the insertion loss on the pin reaches -1dB.

Our pin designs are each characterized on a VNA for frequency bandwidth limits. We also simulate our pins with a 3D solver and model of our customer’s pin configuration, drill cavity and socket base material. The VNA measurements give us our measured pin frequency limits and the simulations confirm our performance and allows us to extend the performance with improvements we can make adjusting the structure PCB board or socket impedance.
