PEC-85-0R32R5-15LM-12-SFF Limiting Amplifier
Available from Planar Monolithics Industries, Inc.
PMI Model No. PEC-85-0R32R5-15LM-12-SFF is a limiting amplifier that operates over the frequency range of 300MHz to 2.5GHz. This model provides a gain of 85dB typically and a limited output of +15dBm ± 2.5dBm. The typical noise figure is 5dB and a maximum VSWR of 2.0:1 is maintained under all operating conditions into a 50 ohm impedance. The operating voltage is +12VDC and the amplifier is reverse voltage protected. The DC current is 485mA typically. The housing measures 5.0" x 1.5" x 0.51". [Other frequency ranges and limited output levels available.]
